Arcade

Arcade is rp1's browser workspace for monitoring tracked workflows, opening their outputs, following external links, and working through feedback while the run context stays visible.

Arcade annotations view showing comments attached to an artifact with surrounding workflow context

Start Arcade

Run Arcade from any rp1 project:

rp1 arcade

By default, Arcade opens in your browser at http://localhost:7710. The project you start from is added to the Projects view, so you can return to its runs, files, and artifacts later.

Useful launch commands:

rp1 arcade --status
rp1 arcade --restart
rp1 arcade --stop
rp1 arcade --port 8080

If the default port is already used by something else, start Arcade on another port with --port. If the browser does not open automatically, copy the URL printed by the command into your browser.

What To Do First

Goal Where to go What to check
See active work Activity Runs marked running, waiting, or failed
Find decisions Notifications drawer Action-required and attention items
Inspect a run Run detail Current status, step list, artifacts, and messages
Read generated work Artifact viewer Requirements, designs, reviews, reports, diagrams, or diffs
Follow outside context Artifact list External links such as reviewed PRs
Leave feedback Annotations Comments, replies, resolved items, and orphaned comments
Switch projects Projects Recent runs and file browser for each registered project

Monitor A Workflow

  1. Start a tracked workflow in your coding host.
  2. Open Arcade and use Activity to find the run.
  3. Open the run detail view.
  4. Check whether the run is running, waiting, completed, failed, cancelled, or inactive.
  5. Use the step list to see where the workflow is.
  6. Open artifacts from the right panel as they appear.
  7. Use notifications when Arcade shows a decision or follow-up that needs your attention.

Arcade is most useful for workflows that take more than a few seconds, produce durable artifacts, or pause for user decisions.

Respond To Waiting Work

When a workflow needs input, Arcade marks the run as waiting and may add a notification. Open the linked run, read the current message and artifacts, then answer in the host conversation that started the workflow.

Common waiting moments include:

  • requirements approval
  • design or plan approval
  • dirty worktree decisions
  • manual verification
  • release readiness
  • archive or follow-up choices

Run details show generated files and external links together in the artifact area. File artifacts open inside Arcade. External links open outside Arcade, so reviewed PRs, issue trackers, and other web destinations stay in their original tools.

Use the artifact viewer to:

  • read Markdown reports and plans
  • scan headings with the outline
  • inspect rendered diagrams
  • view JSON, diffs, and code snippets
  • add or resolve annotations on supported content

See Artifact Viewer for the full reading workflow.

Use Annotations For Feedback

Annotations attach comments to artifact text. They are useful when you want an agent or teammate to revise a specific requirement, design decision, review finding, or generated note.

Typical flow:

  1. Select the relevant text in an artifact.
  2. Add a comment.
  3. Continue the workflow or ask a teammate to review it.
  4. Reply in the annotation thread if more context is needed.
  5. Resolve the annotation when the issue is addressed.

If the artifact changes and Arcade cannot find the original selected text, the comment is preserved as orphaned so you can decide whether it still applies.

See Annotations for details.

Main Surfaces

Surface Use it for
Dashboard Activity, filters, notifications, run details, projects, and workspaces
Artifact Viewer Reading files, following links, switching views, and opening annotation tools
Annotations Adding comments, replying, resolving, reopening, and handling orphaned feedback
Keyboard Shortcuts Moving quickly through Activity, Projects, workspaces, and overlays
Settings Adjusting Arcade preferences
